TRAX TX-01 Cast Iron Ball Float Steam Trap
TRAX TX-01 Cast Iron Ball Float Steam Trap. Horizontal cast iron ball float steam trap with Steam Lock Release (SLR). Body and bonnet are cast iron, with stainless steel internal working parts. Material: Cast Iron, BS:1452 Gr. 220; Internal Working Parts: Stainless Steel, AISI 304; Type: Horizontal ball float steam trap with Steam Lock Release (SLR); End Connection: Screwed female BSP parallel threads to BS:21; Working Pressure: 10 bar; Listed Si
Available Size / Variant
Confirm size with quotation
Brand / MakeTRAX
Catalogue ModelTX-01
Product FamilyBoiler / Steam Accessory
MaterialCast Iron, BS:1452 Gr. 220; Internal Working Parts: Stainless Steel, AISI 304; Type: Horizontal ball float steam trap with Steam Lock Release (SLR); End Connection: Screwed female BSP parallel threads to BS:21; Working Pressure: 10 bar; Listed Sizes: 15 mm; 20 mm; 25 mm; 40 mm; 50 mm
TRAX Catalogue Technical Data
Technical information below is taken from the supplied catalogue file. Please confirm current availability and final quoted specification before ordering.
Body & Bonnet MaterialCast Iron, BS:1452 Gr. 220; Internal Working Parts: Stainless Steel, AISI 304; Type: Horizontal ball float steam trap with Steam Lock Release (SLR); End Connection: Screwed female BSP parallel threads to BS:21; Working Pressure: 10 bar; Listed Sizes: 15 mm; 20 mm; 25 mm; 40 mm; 50 mm
