TRAX TX-151 Stainless Steel Parallel Slide Blow Down Valve
TRAX TX-151 Stainless Steel Parallel Slide Blow Down Valve. Stainless steel parallel slide blow down valve, rack and pinion operated with key. The valve uses renewable seat and disc construction with Stellite trim seat and Class 300 flanged ends. Material: ASTM A743, CA-40; Class: CL-300; Operation: Rack & pinion operated with key; Seat: Renewable; Disc: Renewable; Trim Seat: Stellite; End Connection: Flanges CL-300; Working Pressure: Max. B.O.P.
Available Size / Variant
Confirm size with quotation
Brand / MakeTRAX
Catalogue ModelTX-151
Product FamilyBoiler / Steam Accessory
MaterialASTM A743, CA-40; Class: CL-300; Operation: Rack & pinion operated with key; Seat: Renewable; Disc: Renewable; Trim Seat: Stellite; End Connection: Flanges CL-300; Working Pressure: Max. B.O.P. 350 psig (24.1 bar) at 425°C; Test Pressure: 700 psig (48.3 bar) hydraulic; Listed Sizes: 25 mm; 40 mm; 50 mm
TRAX Catalogue Technical Data
Technical information below is taken from the supplied catalogue file. Please confirm current availability and final quoted specification before ordering.
MaterialASTM A743, CA-40; Class: CL-300; Operation: Rack & pinion operated with key; Seat: Renewable; Disc: Renewable; Trim Seat: Stellite; End Connection: Flanges CL-300; Working Pressure: Max. B.O.P. 350 psig (24.1 bar) at 425°C; Test Pressure: 700 psig (48.3 bar) hydraulic; Listed Sizes: 25 mm; 40 mm; 50 mm
