VTM VA-131 WCB SWING CHECK VALVE F/E
VTM VA-131 WCB SWING CHECK VALVE F/E. WCB SWING CHECK VALVE F/E. Rating: Class 300. Body/material: Cast Steel / WCB. End connection: Flanged.
Available Size / Variant
DN50-DN300
Brand / MakeVTM
Catalogue ModelVA-131
Product FamilyCheck Valve / NRV
MaterialCast Steel / WCB
Pressure / RatingClass 300
StandardAPI 6D / BS 1868 / ASME B16.34
End ConnectionFlanged
VTM Catalogue Technical Data
Technical information below is taken from the supplied catalogue file. Please confirm current availability and final quoted specification before ordering.
Product StandardAPI 6D / BS 1868 / ASME B16.34
Pressure/Class RatingClass 300
Body Material / StandardCast Carbon Steel (ASTM A216 Gr. WCB)
TrimStainless Steel (ASTM A276 Gr. 410 or ASTM A217 Gr. CA-15)
End DetailsFlanged Class 300
Test PressureShell: 78.5 Kg/cm² Hyd.
Seat57.5 Kg/cm² Hyd. 7.1 Kg/cm² Air.
Face-to-Face StandardAPI 6D / ASME B16.10
Testing StandardAPI 598
End Connection StandardASME B16.5 Class 300
Available SizesDN50-DN300
CertificationIBR
Design StandardAPI 6D / BS 1868 / ASME B16.34
Face-to-FaceAPI 6D / ASME B16.10
Flange StandardASME B16.5 Class 300
Size RangeDN50-DN300
GA DrawingVA-131-IBR-GA-00
