UTAM UV-121-S CONTROLLABLE FEED CHECK VALVE
UTAM UV-121-S CONTROLLABLE FEED CHECK VALVE. CONTROLLABLE FEED CHECK VALVE. Screwed in cover, O/S & Yoke Type. Rating: Max. BOP17.24 Bar at 225°C.. Body/material: Bronze. End connection: Flanged.
Available Size / Variant
Confirm size with quotation
Brand / MakeUTAM
Catalogue ModelUV-121-S
Product FamilyCheck Valve / NRV
MaterialBronze
Pressure / RatingMax. BOP17.24 Bar at 225°C.
End ConnectionFlanged
UTAM Catalogue Technical Data
Technical information below is taken from the supplied catalogue file. Please confirm current availability and final quoted specification before ordering.
Body Material / StandardBronze (IBR Clause 282 (a) (IV) Gr.B)
Type of SeatRenewable Seat
Type of DiscRenewable Disc
TrimSS (ASTM A276 Type 410)
Gland PackingGraphited Asbestos
End DetailsFlanges as per BS:10 Table-H (Und
Working PressureMax. BOP17.24 Bar at 225°C.
Test PressureTested to 34.5 Bar Hyd.
NoteFor Size 11/4" and above, Valve shall have Bolted Bonnet
CertificationIBR Certified
