VTM VA-114 WCB GATE VALVE F/E

Name: VTM VA-114 WCB GATE VALVE F/E
Brand: VTM
SKU: VA-114

VTM VA-114 WCB GATE VALVE F/E. WCB GATE VALVE F/E. Rating: Class 150. Body/material: Cast Steel / WCB. End connection: Flanged, Butt Weld.

About this exact size

This page represents one specific size variant. Confirm the model, material, pressure/rating, end connection, applicable standard, quantity and delivery location in your RFQ so the quotation is for the exact product shown rather than a nearby size or class.

Available Size / Variant

40-600 mm

Brand / MakeVTM

Catalogue ModelVA-114

Product FamilyGate Valve

MaterialCast Steel / WCB

Pressure / RatingClass 150

StandardAPI 600

End ConnectionFlanged, Butt Weld

VTM Catalogue Technical Data

Technical information below is taken from the supplied catalogue file. Please confirm current availability and final quoted specification before ordering.

Pressure/Class RatingClass 150

Body Material / StandardCast Carbon Steel (ASTM A216 Gr. WCB)

TrimSS (ASTM A276 Gr. 410 or Equivalent)

Type of WedgeSolid / Flexible Wedge

PackingPure Graphite

OperationHand Wheel Operated upto 350mm & above are Gear operated.

End DetailsFlanges Drilled as per ASME B16.5 #150 Butt-Weld Ends to Suit ASME B16.25

Test PressureShell: 30.0 Kg/cm² Hyd.

Seat22.0 Kg/cm² Hyd.

Product StandardAPI 600

Face-to-Face StandardASME B16.10

Testing StandardAPI 598

End Connection StandardASME B16.5 Class 150

Available Sizes40-600 mm

CertificationIBR

Design StandardAPI 600

Face-to-FaceASME B16.10

End Connection StandardASME B16.5

RatingClass 150

Size Range40-600 mm

GA DrawingVA-114-IBR-GA-00

Individual Size Product Pages

Each available size has its own product page for precise enquiry and specification reference.

40mm (1 1/2")50mm (2")65mm (2 1/2")80mm (3")100mm (4")125mm (5")150mm (6")200mm (8")250mm (10")300mm (12")350mm (14")400mm (16")450mm (18")500mm (20")600mm (24")
