VTM VA-1803DP C.I. WAFER TYPE BUTTERFLY VALVE WITH PNEUMATIC ACTUATOR
VTM VA-1803DP C.I. WAFER TYPE BUTTERFLY VALVE WITH PNEUMATIC ACTUATOR. C.I. WAFER TYPE BUTTERFLY VALVE WITH PNEUMATIC ACTUATOR. Double Acting Type with Air pressure of 8 Bar (Maximum). Rating: PN16. Body/material: Cast Iron. End connection: Wafer.
Available Size / Variant
Confirm size with quotation
Brand / MakeVTM
Catalogue ModelVA-1803DP
Product FamilyPneumatic Actuated Butterfly Valve
MaterialCast Iron
Pressure / RatingPN16
StandardAPI 609 / BS EN 593 / IS 13095
End ConnectionWafer
VTM Catalogue Technical Data
Technical information below is taken from the supplied catalogue file. Please confirm current availability and final quoted specification before ordering.
Product StandardAPI 609 / BS EN 593 / IS 13095
Pressure/Class RatingPN16
Body Material / StandardEpoxy Coated Cast Iron (1S 210 Gr. FG260)
Type of DiscStainless Steel (ASTM A351 Gr. CF8)
Stem(ASTM A479 Gr. 410)
Type of SeatReplaceable EPDM Liner
BearingSelf Lubricated Sliding Bearings
ActuatorDouble Acting Type with Air pressure of 8 Bar (Maximum)
End DetailsSuitable for Insertion B/W ASME B16.5 #150 BS 10 Table D/E / BS 1092 PN10/16
Test PressureShell: 24.5 Kg/cm² Hyd.
Seat18 Kg/cm² Hyd. 7.1 Kg/crm? Air.
