VTM VA-268 WCB BALL VALVE 3PC. DESIGN S/E
VTM VA-268 WCB BALL VALVE 3PC. DESIGN S/E. WCB BALL VALVE 3PC. DESIGN S/E. Rating: PN 40. Body/material: Cast Steel / WCB. End connection: Screwed.
Available Size / Variant
Confirm size with quotation
Brand / MakeVTM
Catalogue ModelVA-268
Product FamilyBall Valve
MaterialCast Steel / WCB
Pressure / RatingPN 40
StandardBS EN ISO 17292
End ConnectionScrewed
VTM Catalogue Technical Data
Technical information below is taken from the supplied catalogue file. Please confirm current availability and final quoted specification before ordering.
Product StandardBS EN ISO 17292
Pressure/Class RatingPN 40
Port OpeningFull Bore
Body Material / StandardCast Carbon Steel (ASTM A216 Gr. WCB)
BallStainless Steel (ASTM A351 Gr. CF8 / ASTM A276 Gr.304)
StemStainless Steel (ASTM A276 Gr. 304)
Seat Ring & Gland Packing‘Viirgin PTFE
End Details‘Screwed Female BSP Parallel Threads to BS: 21
Test PressureShell: 61.5 Kg/cm² Hyd.
Seat45.0 Kg/cm² Hyd. 7.1 Kg/em? Air
