AUDCO PN16 Butterfly Valve - Cast Iron, EPDM, Stainless Steel CF8, Gear unit
AUDCO PN16 wafer butterfly valve with an integrally moulded elastomer body liner, vulcanised in-situ and bonded directly to the body. The catalogue describes integral gasket sealing, secondary moulded O-ring shaft sealing and a weatherseal. Catalogue code IBG3RS decodes to a Cast Iron body, wafer flangeless, gear unit, EPDM liner, Stainless Steel CF8 disc and Stainless Steel 410 with PTFE coating shaft. Please confirm current availability and final quoted specification before ordering.
Available Size / Variant
DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600
Brand / MakeAUDCO
Product FamilyButterfly Valve
MaterialCast Iron
AUDCO Catalogue Technical Data
Technical data below is carried from the supplied manufacturer catalogue file. Please confirm current availability and final quoted specification before ordering.
Catalogue ModelIBG3RS
Pressure classPN16
Body materialCast Iron
Body styleWafer flangeless
OperationGear unit
Body linerEPDM
Disc materialStainless Steel CF8
Shaft materialStainless Steel 410 with PTFE coating
Valve design standardsEN 593
SpecificationAPI 609
SpecificationMSS SP-67
Pressure testing standardEN 12266-1
Available sizesDN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600
