AUDCO Series 519 Fire-Safe 1-Piece Full Bore Flanged Ball Valve
AUDCO Series 519 1-piece full-bore flanged ball valve in ASTM A351 CF8M. The supplied model list identifies this variant as fire-safe. A separate model-specific technical bulletin was not supplied for this series, so the record is limited to the technical attributes explicitly shown in the supplied documents. Please confirm current availability and final quoted specification before ordering.
Available Size / Variant
DN15, DN20, DN25, DN40
Brand / MakeAUDCO
Product FamilyBall Valve
MaterialASTM A351 CF8M
Pressure / Rating150
Standard / Specification519
End ConnectionFlanged
AUDCO Catalogue Technical Data
Technical data below is carried from the supplied manufacturer catalogue file. Please confirm current availability and final quoted specification before ordering.
Catalogue ModelLF51966TTF1
Series519
Technical rating150
Body materialASTM A351 CF8M
Construction1-piece
BoreFull
End connectionFlanged
Fire-safeYes
Available sizesDN15, DN20, DN25, DN40
