Cast Iron, EPDM - 250mm (10") AUDCO BUTTERFLY VALVE CAST IRON BODY SG IRON - 250mm (10") - PN 16 is listed in our Butterfly Valve catalogue with Cast Iron, PN 16. Please confirm current availability and the final applicable specification in our quotation before ordering.
Published catalogue recordCast Iron, EPDM - 250mm (10") AUDCO BUTTERFLY VALVE CAST IRON BODY SG IRON - 250mm (10") - PN 16 is listed in our Butterfly Valve catalogue with Cast Iron, PN 16. Please confirm current availability and the final applicable specification in our quotation before ordering.
Brand / MakeAUDCO
Product TypeButterfly Valve
Size250mm (10")
MaterialCast Iron
Pressure / RatingPN 16
AUDCO Catalogue Technical Data
Technical data below is carried from the supplied manufacturer catalogue file. Please confirm current availability and final quoted specification before ordering.
AUDCO PN16 wafer butterfly valve with an integrally moulded elastomer body liner, vulcanised in-situ and bonded directly to the body. The catalogue describes integral gasket sealing, secondary moulded O-ring shaft sealing and a weatherseal. Catalogue code IBG3JS decodes to a Cast Iron body, wafer flangeless, gear unit, EPDM liner, SG Iron coated with nylon disc and Stainless Steel 410 with PTFE coating shaft.
Catalogue ModelIBG3JS
Pressure classPN16
Body materialCast Iron
Body styleWafer flangeless
OperationGear unit
Body linerEPDM
Disc materialSG Iron coated with nylon
Shaft materialStainless Steel 410 with PTFE coating
Valve design standardsEN 593
SpecificationAPI 609
SpecificationMSS SP-67
Pressure testing standardEN 12266-1
Available sizesDN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600
