UTAM UV-254-S PARALLEL SLIDE VALVE
UTAM UV-254-S PARALLEL SLIDE VALVE. PARALLEL SLIDE VALVE. Rack & Pinion Operated with Key. Rating: Max. B.0.P. 350 Psig (24.1Bar)at 800°F.(427°. Body/material: Cast Steel / WCB. End connection: Flanged.
Available Size / Variant
Confirm size with quotation
Brand / MakeUTAM
Catalogue ModelUV-254-S
Product FamilyGate Valve
MaterialCast Steel / WCB
Pressure / RatingMax. B.0.P. 350 Psig (24.1Bar)at 800°F.(427°
End ConnectionFlanged
UTAM Catalogue Technical Data
Technical information below is taken from the supplied catalogue file. Please confirm current availability and final quoted specification before ordering.
Body Material / StandardCast Steel (ASTM A216 Gr.WCB).
Type of SeatRenewable Seat
Type of DiscRenewable Disc
TrimLumina (Ni-Cu Alloy)
End DetailsFlanges as per BS:10 Table-J (Und
Working PressureMax. B.0.P. 350 Psig (24.1Bar)at 800°F.(427°
Test PressureTested to 700 Psig (48.3 Bar) Hyd.
CertificationIBR Certified
