65mm or 2 1/2" NB MS FLANGE - MILD STEEL IS 2062 GR B FLANGE AS PER BS 10 TABLE F
65mm or 2 1/2" NB MS FLANGE - MILD STEEL IS 2062 GR B FLANGE AS PER BS 10 TABLE F is carried forward from the previous Tubes & Valves OpenCart catalogue and is grouped under Flanges › MS Flange › MS Slipon Flange › MS Flange Slipon BS10 Table F. Manufacturer / make: TMI. Legacy model / reference: 1003. Please confirm current availability, final technical specification and commercial terms in the quotation before ordering.
Available Size / Variant
65mm (2 1/2")
Manufacturer / MakeTMI
Product FamilyTee
MaterialMild Steel
Standard / SpecificationIS 2062, BS 10
Legacy Model / Ref.1003
Unit / SKUPCS
Dimensional / Size DetailsBS - 10 (1962) Table F
Material CompositionIS 2062 Gr B
CoatingRust Preventive Varnish / Black Japan
BrandTMI
MachiningOne Side
Outer Diameter (OD)184 mm
TypeSlipon / Slip-on
ConnectionWeldable
Hole Diameter18 mm
Inner Diameter (ID)78 mm
Number of Holes8 holes
Other NamesPlate Flange / Companion Flange / Matching Flange / Mating Flange
Tolerance (+/-)Market Tolerance
FacePlain Face / Flat Face
Wall thickness16 mm
Catalogue category: Flanges › MS Flange › MS Slipon Flange › MS Flange Slipon BS10 Table F
